| temperature range |
A：-20℃～150℃ B：-40℃～150℃
C：-60℃～150℃ D：-70℃～150℃ |
| Temperature uniformity |
≤2℃ (at no load) |
| Temperature fluctuation |
±0.5℃ (at no load) |
| Humidity range |
20%～98% RH |
| Humidity uniformity |
+2% -3% RH |
| Humidity fluctuation |
±2% |
| heating rate |
-55℃～125℃ Linear 15℃/min (at no load) |
| cooling rate |
125℃～-55℃ Linear 15℃/min (at no load) |
| Time Setting Range |
1～60000M |
| test hole |
Mounted on the left side of the machine for use with external test power or signal cables |
| viewing window |
395 x 395mm (effective field of view) |
| Outer case material |
High quality A3 steel plate electrostatic spraying |
| Inner box material |
Imported high-grade stainless steel SUS304 |
| Insulation material |
Rigid polyurethane foam + fiberglass |
| Temperature Controller |
Imported “UEC” brand temperature and humidity meter |
| temperature sensor |
PT100 platinum resistance temperature measurement body |
| Cooling method |
Two-machine cascade refrigeration |
| Compressor |
France Tycon/Germany Bitzer/Germany Copeland |
| standard configuration |
Equipped with a condensate catch pan and discharged out of the box |
| security protection |
Compressor overpressure overload, fan motor overheating, the whole machine under phase / reverse phase
Timing, over temperature, leakage protection, overload and short-circuit protection |
| Supply Voltage |
AC380V±10% 50Hz |
| operating environment |
5℃～＋28℃ ≤85% RH |
Note:
1、 the model in the R represents linear, r represents non-linear, the number in parentheses represents the cooling rate
2、Test data are measured in the use of ambient temperature of 25 ℃ and well ventilated conditions
3、Above parameters are for reference only, can be customized according to user-specific test parameters
4、This technical information, subject to change without notice |
