Drop Test Machine|Drop Tester

Drop Test Machine|Drop Tester

Introduction
The Drop Test Machine(Drop Tester) is used to simulate the impact of a packaged product falling onto the ground from various heights, testing different edges, corners, and surfaces. This helps evaluate the extent of product damage and assess the maximum drop height and impact resistance of the packaging components. Based on the test results and within the scope of national standards, improvements …

Phone

400-6400-998
Product Features
Product Parameter
Product Parameter
Formaldehyde VOC environmental test chamber Drop height mm Dimension(D*W*H)mm
LRHS-318-UD 300~1500 1650×1150×2260
Drop height range 300~1500mm
Height display method digital
Maximum specimen size 1000×800×1000mm
Impact Panel Size 1600×1100×14mm
Control box external dimensions 300×350×1100mm
External Dimension of Test Stand 1650× 1150×2260mm
height adjustment motor drive
Falling mode Facets, edges and corners
Drop Plane Error <1°
Drop height error ±10mm (adjustable)
Maximum weight of specimen 75kg
accelerations >7g
security protection Motor failure protection, high and low limit protection, emergency stop, power leakage protection, short circuit protection
Supply Voltage AC380V±10% 50Hz
Power 1.5kW
Note:
1、Can be customized according to the user test requirements of the test maximum weight
2、This technical information is subject to change without prior notice.
